해양 등급 U2 U3 샛기둥 앵커 체인

주요 특성
브랜드 이름: Henger
원산지: 중국
인증: BV,CCS,KR,LR,NK, ABS
공급능력: 달 당 3000 톤
배달 시간: 1-5 주
지불 조건: 전신환, L/C (신용장), 인수 인도, D/P (지급도 조건), 웨스턴 유니온, 머니그램
표준 포장: 벌거벗은 / 팔레트

제품 요약

해양 등급 U2 U3 샛기둥 앵커 체인 U2 U3 샛기둥 앵커 체인 상술 = NORMINAL 체인 지름 (밀리미터) 증명시험 로드(kn) 테스트 로드(kn)를 빵부스러기를 묻히기 중량kg/27.5m GRADE2 GRADE3 GRADE2 GRADE3 17.5 127 179 179 256 194 19 150 211 211 301 236 20.5 175 244 244 349 269 22 200 280 280 401 322 24 237 332 332 476 370 26 278 389 389 556 431 28 321 449 449 642 ...

제품 맞춤 속성

강조하다

U3 스터드 닻사슬

,

해양 등급 U2 샛기둥 앵커 체인

,

CM690 해양 닻사슬

상품 이름:
치안 앵커
마테리아:
CM490,CM690
색:
검어지거나, 고객에 요구입니다
사이즈:
17.5mm-130mm
애플리케이션:
해양 정박
인증:
CCS,BV,LR,RINA,KR,NK,GL,ABS,DNV,RS
보증:
1년이요
피페이먼트 용어:
전신환, 웨스턴 유니온 또는 보자마자 L/C (신용장)
제품 설명

해양 등급 U2 U3 샛기둥 앵커 체인

U2 U3 샛기둥 앵커 체인 상술

=

NORMINAL 체인 지름 (밀리미터)

증명시험 로드(kn) 테스트 로드(kn)를 빵부스러기를 묻히기 중량
kg/27.5m
GRADE2 GRADE3 GRADE2 GRADE3
17.5 127 179 179 256 194
19 150 211 211 301 236
20.5 175 244 244 349 269
22 200 280 280 401 322
24 237 332 332 476 370
26 278 389 389 556 431
28 321 449 449 642 496
30 368 514 514 735 564
32 417 583 583 833 635
34 468 655 655 937 712
36 523 732 732 1050 800
38 581 812 812 1160 887
40 640 896 896 1280 1032
42 703 981 981 1400 1084
44 769 1080 1080 1540 1197
46 837 1170 1170 1680 1310
48 908 1270 1270 1810 1438
50 981 1370 1370 1960 1546
52 1060 1480 1480 2110 1661
54 1140 1590 1590 2270 1791
56 1220 1710 1710 2430 1926
58 1290 1810 1810 2600 2086
60 1380 1940 1940 2770 2249
62 1470 2060 2060 2940 2361
64 1560 2190 2190 3130 2516
66 1660 2310 2310 3300 2676
68 1750 2450 2450 3500 2885
70 1840 2580 2580 3690 3010
73 1990 2790 2790 3990 3274
76 2150 3010 3010 4300 3548
78 2260 3160 3160 4500 3737
81 2410 3380 3380 4820 4030
84 2580 3610 3610 5160 4334
87 2750 3850 3850 5500 4650
90 2920 4090 4090 5840 4976
92 3040 4260 4260 6080 5199
95 3230 4510 4510 6440 5544
97 3340 4680 4680 6690 5780
100 3530 4940 4940 7060 6143
102 3660 5120 5120 7320 6398
105 3850 5390 5390 7700 6773
107 3980 5570 5570 7960 7033
111 4250 5940 5940 8480 7569
114 4440 6230 6230 8890 7983
117 4650 6510 6510 9300 8409
120 4850 6810 6810 9720 8863
122 5000 7000 7000 9990 9143
124 5140 7200 7200 10280 9598
127 5350 7490 7490 10710 9908
130 5570 7800 7800 11140 10382

U2 U3 샛기둥 앵커 체인 점검

우리는 각각 사찰에 조직 내부 시설을 가집니다 :
1.분광계에 의한 화학분석
2.측정 점검
3.역학적 성질 시험, 항복점, 인장 강도, 신장
4.비파괴검사 (NDT) : 엑스레이, 염료 침투 시험, 자분 탐상 검사

5.적하 테스트

해양 등급 U2 U3 샛기둥 앵커 체인 0

우리의 장점

1.우리는 ISO 9000이 찬성했다는 것 이며, 그것이 우리가 고객들에 더 좋고 더 나은 생산물과 서비스를 공급할 수 있게 합니다.

1. 우리는 15년 이상 동안 전문 분야였으며, 그것이 우리가 곳 최상품, 최고이 배달 시간을 맞추게 하고 최상의 가격을 알 수 있게 합니다.

2. 우리의 테크니치알 조사단은 우리의 고객들의 지상에서 엄밀하게 제품을 시험하고 조사하기 위한 우리를 가능하게 하는 제품 제조와 조사에 대하여 매우 잘 알립니다.

4.우리는 안전하게 그리고 경제적으로 제품을 고객들에게 선적하 우리를 가능하게 하는 자사 제품을 수출하는 것 경험이 있습니다.

해양 등급 U2 U3 샛기둥 앵커 체인 1

FAQ

1. 큐 :제품을 주문하는 방법?
한 :세부 사항 조사를 우리, 더 상세한 더 좋은 것에게 보내세요. 예를 들면, 품목 번호, 항목 기술, 재료, 사이즈, 표면 처리, 포장 요구. 가능하다면, 그것은 더 좋어떠한 오해도 피하기 위한 약간의 참조 픽처 또는 그림 또는 우리의 웹사이트로부터의 어떠한 링크도 첨부한다는 것 입니다.


2. 큐 :어바웃 샘플 :
한 :작고 작은 양 샘플은 무료로 있습니다. 단지 당신은 급행료를 지닐 필요가 있습니다.


3. 큐 :배달에 대해 시간을 맞추세요 :
한 :배달 시간은 당신의 요구조건에 따라 있을 수 있습니다. 보통 20 일 후 이내에 수주 증서는 침적됩니다.


4.큐 : 소형에 대해 명령하세요 :
한 :다른 MOQ와 다른 제품이 확인하기 위해 우리에 연락합니다.


5.큐 :어바웃 지불 :
한 :전신환, L/C (신용장), 서쪽 union......, 확인하기 위해 우리에 연락하십시요.


6.큐 :어떻게 내 명령이 수송될 것입니까?
한 :보통 해로로 수송되어 당신의 협정을 받은 후 소량주문 또는 지급 주문은 공중에 의해 또는 특사에 의해 있을 수 있습니다.


7.큐 :당신의 품질 보증이 무엇입니까?
한 :우리는 다른 품질 표준을 충족시킬 수 있는 다른 종류의 제품을 갖. 우리의 숙련된 QC 국무부는 각각 생산 과정 동안 제품을 테스트할 것입니다. 게다가, 포장되고 운반하기 전에, 우리는 각각을 다시 시험할 것입니다.

해양 등급 U2 U3 샛기둥 앵커 체인 2
